Seated Multi-directional Forklift MQC Series 8.0ton
01 - Product Description:
- Brand : MiMA
- Model: MQC80
- Operation Type: Seated
- Load Capacity: 8000kg
- Max. Lifting Height: 8000mm
The MQC80 multi-directional forklift has a lifting capacity of 8 tons. Its mast can move forward or retract as a whole. It is equipped with adjustable-width forks, and features four-wheel steering with independent control. This allows for straight travel, sideways movement, diagonal movement, and pivoting on the spot. When moving sideways, it requires a smaller aisle width, making it particularly suitable for handling long materials.
02 - Applications:
- Handling long materials;
- Material stacking in narrower aisles.
Operation Videos
Multi-directional Forklift MQC80: What You Need to Know
Technical Data
Model |
| MQC |
Vehicle Code |
| MQC80 |
Power type |
| Battery |
Driving type |
| Seated |
Load capacity | Q(kg) | 8000 |
Load center distance | C(mm) | 600 |
Front axle to fork vertical plane distance | x(mm) | 330 |
Wheelbase | y(mm) | 1775 |
Fork tilt range: front/ rear | α/β(°) | 3/5 |
Lift height | h3(mm) | 8000 |
Overall length | l1(mm) | 2400 |
Overall width | b1/b2(mm) | 2890/3170 |
Fork dimensions | l/e/s(mm) | 1200/180/60 |
Fork outside spread | b5(mm) | 600～1550 |
Travelling speed, laden/unladen | km/h | 7～8 |
Travelling speed, laden/unladen, sideways | km/h | 8～9 |
Lift speed, laden/unladen | mm/s | 250/350 |
Lowering speed, laden/unladen | mm/s | 350/250 |
